053-1IP01 - IM 053IP Interface Module, EtherNet/IP I/O

VIPA

VIPA 053-1IP01 - IM 053IP SLIO Interface Module, EtherNet/IP I/O

Write a Review
$386.10

ⓘ Special Pricing Available (details here)

  • Special OEM, System Integrator and Distributor pricing available.
  • Frequent End User program pricing upon request.
  • Contact us for Private Labeling packages.
Adding to cart… The item has been added
Part Number:
053-1IP01
SAP-No.:
10108144

SLIO IM 053IP Interface Module - EtherNet/IP IO


Ordercode: VIPA 053-1IP01
SAP-No.: 10108144

  • EtherNet/IP IO

  • 2-Port Switch RJ45 100BaseTX full duplex

  • Up to 64 peripheral modules

  • Supports FMM (Free Module Mapping)

  • Various diagnostics functions

  • Integrated DC 24V power supply for power and electronic section supply of the periphery modules

  • Supports HotConnect, Easy Maintenance

  • Web server integrated

  • Status LED

Technical Details

  • Input power supply: 24 V

  • Current Consumption: 0.95 A

  • Max. current drain at backplane bus: 3 A

  • Max. current drain load supply: 10 A

  • Power Loss: 3 W

  • Racks, max.: 1

  • Fieldbus: EtherNet/IP

  • Connector: 2 x RJ45

  • Topology: Line Star, Line

  • Transmission speed, max.: 100 Mbit/s

  • Address range inputs, max.: 1000 Byte

  • Address range outputs, max.: 1000 Byte

  • Material: PPE / PPE GF10

  • Mounting: Profile rail 35 mm

  • Dimensions Weight: 48.5 mm

  • Dimensions Height: 109 mm

  • Dimensions Depth: 76.5 mm

  • Net weight: 160 g

  • Gross weight: 175 g

  • Certifications: UL certification, KC certification, UKCA certification, ChinaRoHS certification

  • Operating temperature Max: 60 °C
