Profibus Repeaters
DP-REPEATERS
VIPA offers a wide range of PROFIBUS network components. The range includes one, two and 5-channel PROFIBUS repeaters which are transparent for all PROFIBUS DP protocols but are also suitable for PROFIsafe and MPI. All repeaters have automatic recognition of the transmission rates of 9.6 Kbps - 12 Mbps. These repeaters allow to create reliable star/tree networks and long multi-device spur lines. They are deployed in many applications worldwide and comply with the requirements of the end user.
Features included are network redundancy to even create a more reliable network, EMC and noise interference reduction, keeping of high-speed data transfer, hot-swapable, etc.; all to achieve tremendous cost savings, much longer up times, simple network extensions, in a compact and robust chassis.
SUPPORTED PROTOCOLS
- DP-V0, DP-V1, DP-V2
- FDL
- FMS
- MPI
- PROFIsafe
- PROFIdrive
| 920-1BB10 Repeater B1 |
920-1BD10 Repeater D1 |
920-1CB20 MultiRepeater B2-R |
920-1CB50 MultiRepeater B5-R |
920-1CA50 MultiRepeater A5 |
920-1DB50 MultiRepeater B5-RD |
921-1EB50 MultiSwitch B5-R |
924-1BB10 BusTerm T1 |
|
|---|---|---|---|---|---|---|---|---|
| Insulated Repeater channels (+1 segment; 5 channels = 6 segments) |
1 | 1 | 2 | 5 | 5 | 5 | 5 | Active Termination |
| Transparent for all PROFIBUS DP protocols | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Also for PROFIsafe, FMS and MPI | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| 31 devices per channel | Yes | Yes | Yes | Yes | Yes | Yes | Yes | - |
| 1200 m segment length (depending on the baud rate) | Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| 9.6 Kbps.. 12 Mbps (automatic baud rate recognition) |
Yes | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
| Screw and DB9 connection (Screw pin connectors incl.) |
Yes | M12 | Yes | Yes | or M12 | Yes | Yes | Yes |
| Grounding option configurable (direct or capacitive) | - | - | Yes | Yes | Yes | Yes | Yes | - |
| Integrated terminating resistor (disconnectable) | Yes | - | Yes | Yes | Yes | Yes | Yes | Yes |
| Protection class IP 20 (in accordance with DIN 40 050) | Yes | IP66 | Yes | Yes | IP65 | Yes | Yes | Yes |
| Range of temperature | -20..60° C | -25..70° C | -25..70° C | -25..70° C | -40..75° C | -25..70° C | -25..70° C | -20..60° C |
| Power supply | 19..28 VDC | 9..31 VDC | 9..31 VDC | 9..31 VDC | 10..32 VDC | 9..31 VDC | 9..31 VDC | 19..28 VDC |
| Redundant power supply | Yes | Yes | Yes | Yes | - | Yes | Yes | Yes |
| Optional bus redundancy | - | - | Yes | Yes | - | Yes | Yes | - |
| Alarm contact | - | - | Yes | Yes | - | Yes | Yes | - |
| Telegram check (integrity check) | - | Yes | Yes | Yes | - | Yes | Yes | - |
| Navy/DNV and UL certificated | - | - | - | Yes | - | Yes | - | - |
| Internal DP slave for PROFIBUS diagnosis data | - | - | - | - | - | Yes | - | - |
| Adjustable baud rate per channel (switch function) | - | - | - | - | - | - | Yes | - |
| Replacement of | 973-1BA00 | 973-5BE00 | ||||||
