VIPA 022-1BD00 - SLIO SM022 Digital Output Module, 4DO, 24VDC, 0.5A

VIPA

VIPA 022-1BD00 - SM 022 SLIO Digital Output Module, 4DO, 24VDC, 0.5A

Write a Review
$84.70

ⓘ Special Pricing Available (details here)

  • Special OEM, System Integrator and Distributor pricing available.
  • Frequent End User program pricing upon request.
  • Contact us for Private Labeling packages.
Adding to cart… The item has been added
Part Number:
022-1BD00
SAP-No.:
100-220-832

SLIO SM022 Digital Output Module


Ordercode: VIPA 022-1BD00
SAP-No.: 100-220-832

  • 4 Digital Outputs
  • 24VDC
  • 0.5A



Technical Details

  • Current consumption from backplane bus: 75 mA

  • Power Loss: 0.5 W

  • Number of outputs (digital): 4

  • Rated load voltage (digital output): DC 20.4 - 28.8 V

  • Current consumption from load voltage L+ (without load): 10

  • Signal logic output (digital): Sourcing output

  • Output data size (digital): 4 bit

  • Material: PPE / PPE GF10

  • Mounting: Profile rail 35 mm

  • Width: 12.9 mm

  • Height: 109 mm

  • Depth: 76.5 mm

  • Net weight: 57 g

  • Gross weight: 71 g

  • Certifications: ChinaRoHS certification, UL certification, KC certification, UKCA certification

  • Max. operating temperature: 60 °C

Downloads

Replacement For:

  • Lenze EPM-S301
