VIPA 021-1BD40 - SM021 Digital Input Module, 4DI, 24VDC, 2/3 Wire

VIPA

VIPA 021-1BD40 - SM 021 SLIO Digital Input Module, 4DI, 24VDC, 2/3 Wire

Write a Review
$68.20

ⓘ Special Pricing Available (details here)

  • Special OEM, System Integrator and Distributor pricing available.
  • Frequent End User program pricing upon request.
  • Contact us for Private Labeling packages.
Adding to cart… The item has been added
Part Number:
021-1BD40
SAP-No.:
100-220-786

SLIO SM 021 - Digital Input Module


Ordercode: VIPA 021-1BD40
SAP-No.: 100-220-786

  • 4 Digital Inputs
  • 24VDC
  • Connect 2/3 Wire



Technical Details

  • Current consumption from backplane bus: 65 mA

  • Power Loss: 0.6 W

  • Number of inputs (digital): 4

  • Signal logic input (digital): Sinking input

  • Input characteristic curve (digital): IEC 61131-2, type 1

  • Initial data size (digital): 4 bit

  • Material: PPE / PPE GF10

  • Mounting: Profile rail 35 mm

  • Width: 12.9 mm

  • Height: 109 mm

  • Depth: 76.5 mm

  • Net weight: 57 g

  • Gross weight: 71 g

  • Certifications: UL certification, KC certification, UKCA certification, ChinaRoHS certification

  • Max. operating temperature: 60 °C

Downloads

Replacement For:

  • Lenze EPM-S203
