EWON EC7133J - Cosy+ WIFI Router, 4x RJ45 LAN/WAN ports, WIFI 802.11 b/g/n

Write a Review

ⓘ Special Pricing Available (details here)

  • Special OEM, System Integrator and Distributor pricing available.
  • Frequent End User program pricing upon request.
  • Contact us for Private Labeling packages.

Adding to cart… The item has been added
Part Number:
0.47 LBS

EWON EC7133J Cosy+ WIFI Router

Industrial Internet Router: Ewon Cosy+ WIFI, 4x RJ45 LAN/WAN ports, WIFI 802.11 b/g/n

EC7133J Features:

  • WAN Connectivity: Ethernet or WiFi: 802.11 a/b/g/n.

  • Frequencies: Channels: 1 to 11(inclusive).

  • Security: Client : WPA, WPA2 and WEP. Access Point : WPA2.

  • Antenna Connector: RP-SMA female connector.

  • Antenna: Included in the delivery. Antenna covering the ISM band for WLAN system 802.11 a/b/g/n. The antenna has SMA connector and can be tilted 90 degrees.

    • Client : frequency and gain: 2.4GHz / 2.0dBi max and 5 GHz /4.5dBi max.; impedance: 50 Ohms.

    • Access point : frequency: 2.4GHz; gain: 2.0dBi max; impedance: 50 Ohms

  • WAN Ethernet: up to 3 ports,10/100 Mb Ethernet.

  • LAN Ethernet: up to 4 ports,10/100 Mb Ethernet.

  • Field interface: Up to 10 USB 2.0 connections, female connector 2.0.

  • SD Card reader: YES, for Cosy commissioning (firmware upgrade, backup, Talk2M registration).

  • Router: IP filtering, IP forwarding, NAT, Port forwarding, Proxy, Routing table, DHCP client/server.

  • Internet: Outbound connection for Talk2M through port TCP 443 (and optionally port UDP 1194).

  • VPN Tunneling: OpenVPN either in SSL UDP or TCP.

  • Talk2M: Talk2M Free+ or Talk2M Pro, natively supported.

  • VPN Security: Communications between the remote user and the Ewon are fully encrypted using the SSL/TLS protocol, thereby ensuring data authenticity, integrity & confidentiality. All users and Ewon units are authenticated using x509 SSL certificates and end-to-end traffic is encrypted using strong symmetric & asymmetric algorithms that are part of the SSL/TLS protocol cipher suite.

  • Synchronization: Embedded real-time clock, manual setup via the web interface or automatic via NTP.

  • File Management: FTP server for configuration, firmware update.

  • Web-based configuration: Embedded web interface with setup wizards for configuration and maintenance (no additional software needed). Basic authentication (login/password) and session control for security.

  • Mechanicals: Dimensions: 108,80 x 99 x 43,60 mm (H x D x W). DIN rail or wall screw fixing system.

  • Weight: 214 gr.

  • Power supply: 12-24 VDC +/-20%, LPS.

  • Temperature Range: Operating: -25°C to +60°C, 10 to 95% relative humidity (non-condensing). Storage: -30°C to +70°C, 10 to 95% relative humidity (non-condensing).

  • Hardware: 1xDO: open drain (MOSFET) 200mA; isolation 1.5kV, 2xDI: 0 to 24VDC; 1.5 kV isolation.

  • Marking: CE, cULus, FCC, UKCA, Japan, RCM
